Email us for availability before ordering! Kohler 20kW 20RCA Residential Standby Generator 3 Phase 120/240v
Overview
Our most popular generators for backup power provide award-winning reliability and performance. When you lose power during an outage or storm, a hard-working 14/20 kW KOHLER® generator keeps your appliances working, the heat or AC running and your security system on. Now also available in 3 phase.*
Reliable.
Every KOHLER® generator is equipped with a heavy-duty, commercial-grade engine that stands up to extreme weather.
Powerful.
In just 10 seconds, your KOHLER generator automatically restores power to a 5-ton (60,000 BTU) air conditioner, major appliances and electronics.*
Premium warranty.
We’ve got you covered with 5-year, 2,000-hour protection, and a corrosion-proof enclosure that’s built to last.
Award winner.
KOHLER generators have received several awards, including the Most Valuable Product (MVP) Award 2010 by Building Products magazine.
THE POWER YOU NEED
PowerBoost™ technology provides power to start large loads such as central air conditioners without dropping power to other appliances
Extraordinary peak motor-starting capacity: 14RCA at 33kVA at 240V and 20RCA at 41kVA at 240V
Premium power quality delivers exceptional digital voltage and frequency regulation along with low levels of harmonic distortion to protect sophisticated electronics
Powered by reliable KOHLER Command PRO® engine, designed and tested for tough commercial applications; with hydraulic valve lifters to eliminate need for lengthy break-in periods and expensive valve adjustments; operation speed is 3600 rpm (the standard for air-cooled generators)
Compatible with OnCue® Plus and OnCue® Plus Wireless Generator Management Systems, and Programmable Interface Module (PIM)
Also compatible with Load Control Module (LCM) or Load Shed kit with single-phase generators only
THE CONVENIENCES YOU EXPECT
RDC2 controller designed for today’s sophisticated electronics manages both the generator set and Model RXT transfer switch functions
Quiet, neighborhood-friendly operation with sound levels similar to a typical central air conditioner
Stylish corrosion-proof enclosure impact tested to -30°F
Runs on either natural gas or liquid propane (LPG) with simple switching between natural gas and LPG in the field
Streamlined installation, simple terminal block for easy field connections. Kohler also offers concrete mounting pads to lower installation costs and time.
Streamlined installation, simple terminal block for easy field connections. Kohler also offers concrete mounting pads to lower installation costs and time.
All information shown is for 1 Phase 60 Hz generator with the largest alternator option available.
Displacement
999 cm³ (61 cu. in.)
Horsepower
NG 27.1 HP, LP 30.9 HP
Enclosure Material
Aluminum
Sound Output During Weekly Exercise
64 dB(A)
Sound Output During Full-speed Operation
69 dB(A)
Response Time
10 seconds
Warranty
Premium five-year limited warranty
Country of Origin
US
Certifications/Listings
EPA|cUL|UL 2200|CSA
Automatic Transfer Switch Included
Sold Separately
Remote Monitoring Available
Included
Off Grid / Utility Backup
Utility Backup
Weight
555 lbs. (252 kg)
Alternator Type
2-Pole, Rotating Field
Fuel Consumption on NG at 50% load?
161 cfh
Fuel Consumption on LP at 50% load?
82 cfh
Controller
RDC2 Controller
Cylinder Arrangement
V-2
Dimensions
1193 mm x 666 mm x 817 mm (47 in. x 26.2 in. x 32.2 in.)
Engine Manufacturer/Description
KOHLER
Engine Model
CH1000
Engine/Alternator RPM
3600
Fuel Type
Natural Gas|LPG
Frequency
60 Hz
Phase
Single Phase or Three Phase
Voltage @ 60 Hz
120/240|277/480
Digital Voltage Regulation
±1.0%
Built in Mounting Pad
Yes
Weight
555 lbs
